TP3-17 Expansion Tank Cap | 1.2 Bar Yellow (62 mm, Internal Thread)
TP3-17 is a yellow screw-on coolant expansion tank cap rated at 1.2 bar (120 kPa), 62 mm outer diameter with an internal thread. In the TecDoc catalogue this cap is listed against Chevrolet, Ford and Isuzu applications. Note the difference from our TP3-20: same pressure and colour, but TP3-20 is 60 mm with an external thread. Check which way your bottle’s thread runs before ordering.
Key Features
- Yellow screw-on expansion bottle cap, 62 mm, internal thread
- Calibrated 1.2 bar (120 kPa) pressure rating
- Cures pressure loss, overheating and constant top-ups
- Entry price with OE-quality sealing
- Pair check: internal thread = TP3-17, external thread = TP3-20
Specifications
- OE reference: Ford XS61 8100 AB
- Opening pressure: 1.2 bar (120 kPa / approx. 17 psi)
- Outer diameter: 62 mm · Height: 25 mm · Colour: yellow
- Mounting: screw connection, internal thread
- Part reference: TP3-17 (cross: OSSCA 11769, OSSCA 11769)
Vehicle Applications | What This Cap Fits
The TecDoc parts catalogue lists 23 vehicle applications for this cap across Chevrolet, Ford and Isuzu. Vehicle listings are a guide only. Always match the pressure stamping, neck size and reach of the cap you are replacing before ordering.
How to Check You Have the Right Cap
The pressure rating is printed on your original cap. Match the pressure and the cap style, or bring your old cap to our Kempton Park counter and we will match it for you. Never open a radiator or expansion cap while the engine is hot.
Radiator Cap Range at Greyhound Auto Retail
Clip-on metal caps (Neptune): RC1-13, RC1-16, RC2-13, RC2-16 and the full RC3G 60-27 family from 48 to 124 kPa. Screw-on expansion tank caps: 1.2 bar yellow (60 mm and 62 mm), 1.4 bar black, and the 2.0 bar Neptune BMW cap.
Buying oil too? Engine oil of R300 or more gets you 10% off all filters, added automatically at checkout.
